PB0027NLT
RoHS
RoHS compliant
RoHS compliantPackage 200
Category Transformers / Current Sense Transformers
Description
Current Transformers TRANSFORMER CURRENT SENSE
PDF
/
Buying Options
Total Price: USD $3.35
Unit Price: USD $3.3528
≥1 USD $3.3528
≥10 USD $2.7192
≥100 USD $2.198592
≥500 USD $2.059904
≥1000 USD $1.96724
Inventory: 1154
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 13.46mm
Length 14.22mm
Height Seated (Max) 0.394 10.00mm
Height 10mm
Technical
Load Resistance 175Ohm
Number of Primary Winding 1
Number of Secondary Winding 1
Turns Ratio - Primary:Secondary 1:200
Isolation Voltage 500V
Frequency Range 50kHz~500kHz
Application POWER
Lead/Base Style Gull Wing
Max DC Current 35A
DC Resistance (DCR) 0.42mOhm Primary 2.9Ohm Secondary
Inductance 22.4mH
Termination Style Gull Wing
Frequency 500Hz
Current Rating 35A
Depth 19.91mm
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Type Invasive
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.591Lx0.784W 15.00mmx19.91mm
Series PB002XNL
Published 2008
Packaging Tape & Reel (TR)
Physical
Number of Pins 10
Package / Case 200
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
