PB0026NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
CURR SENSE XFMR 100:1 35A SMD
PDF
/
Buying Options
Total Price: USD $4.9
Unit Price: USD $4.90317
≥1 USD $4.90317
≥10 USD $1.957101
≥100 USD $1.891818
≥500 USD $1.858482
Inventory: 7935
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 13.46mm
Length 14.22mm
Height Seated (Max) 0.394 10.00mm
Height 10mm
Technical
Load Resistance 43.6Ohm
Turns Ratio - Primary:Secondary 100:1
Frequency Range 50kHz~500kHz
Lead/Base Style Gull Wing
DC Resistance (DCR) 0.42mOhm Primary 1.4Ohm Secondary
Inductance 5.6mH
Termination Style Gull Wing
Frequency 500kHz
Current Rating 35A
Depth 19.91mm
Shielding Unshielded
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Terminal Finish Matte Tin (Sn)
Type Invasive
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.591Lx0.784W 15.00mmx19.91mm
Series PB002XNL
Published 2008
Packaging Tray
Physical
Number of Pins 10
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
