PB0025NLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
XFRMR CURR SENSE 1.4MH 50:1 SMD
PDF
/
Inventory: 6303
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Technical
Packaging Tape & Reel (TR)
Published 2008
Series PB002XNL
Size / Dimension 0.591Lx0.784W 15.00mmx19.91mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Type Invasive
Max Operating Temperature 130°C
Min Operating Temperature -40°C
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Current Rating 35A
Frequency 500kHz
Termination Style Gull Wing
Physical Dimension L14.22XB13.46XH10.16 (mm)
Inductance 1.4mH
DC Resistance (DCR) 0.42mOhm Primary 700mOhm Secondary
Lead/Base Style Gull Wing
Frequency Range 50kHz~500kHz
Turns Ratio - Primary:Secondary 50:1
Load Resistance 11Ohm
Dimensions
Height 10mm
Height Seated (Max) 0.394 10.00mm
Length 14.22mm
Width 13.46mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
