PA3202NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
CURR SENSE XFMR ROGOWSKI 200A
PDF
/
Buying Options
Total Price: USD $6.21
Unit Price: USD $6.2128
≥1 USD $6.2128
≥10 USD $4.6596
≥100 USD $4.14179
≥500 USD $3.934762
≥1000 USD $3.831168
≥3000 USD $3.209897
Inventory: 1488
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.580 14.73mm
Technical
Turns Ratio - Primary:Secondary Rogowski Coil
Frequency Range 50/60Hz
DC Resistance (DCR) 54Ohm Max
Inductance 1.75mH
Termination Style Wire Leads
Frequency 60Hz
Current Rating 200A
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Type Non-Invasive (Solid Core)
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 1.669Lx1.587W 42.40mmx40.30mm
Series Sidewinder?, PA32XXNL
Published 2013
Packaging Tray
Physical
Mounting Type Chassis Mount
Mount Cable, Chassis Mount
Supply Chain
Factory Lead Time 11 Weeks
