PA1005.040QNL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
CURR SENSE XFMR 1:40 20A SMD
PDF
/
Buying Options
Total Price: USD $2.99
Unit Price: USD $2.986848
≥1 USD $2.986848
≥240 USD $1.192113
≥480 USD $1.152726
≥960 USD $1.133033
Inventory: 7127
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.217 5.50mm
Technical
Turns Ratio - Primary:Secondary 1:40
Frequency Range 50kHz~1MHz
DC Resistance (DCR) 0.75mOhm Primary 1.14Ohm Secondary
Inductance 320μH
Termination Style Gull Wing
Current Rating (Amps) 20A
Type Invasive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.284Lx0.330W 7.21mmx8.38mm
Packaging Tray
Physical
Weight 0.014oz 0.4g
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
