P8202NLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
XFRMR CURR SENSE 0.08MH 1:20 SMD
PDF
/
Buying Options
Total Price: USD $2.55
Unit Price: USD $2.552
≥1 USD $2.552
≥10 USD $2.03808
≥100 USD $1.65616
≥500 USD $1.613568
≥1000 USD $1.571152
≥3000 USD $1.52863
Inventory: 1252
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 8.38mm
Height Seated (Max) 0.217 5.50mm
Height 5.5mm
Technical
Load Resistance 0.55Ohm
Turns Ratio - Primary:Secondary 1:20
Frequency Range 50kHz~1MHz
Lead/Base Style Gull Wing
Max DC Current 10A
DC Resistance (DCR) 6mOhm Primary 550mOhm Secondary
Inductance 80μH
Physical Dimension L8.38XB7.21XH5.5 (mm)
Termination Style Gull Wing
Frequency 1MHz
Current Rating 10A
Depth 7.21mm
Additional Feature LENGHT DIMENSION INCLUDES TERMINAL ALSO
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Type Invasive
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.284Lx0.330W 7.21mmx8.38mm
Series P820X
Published 2008
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
Alternative Model
