P0582NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
Current Transformer 100: 1: 1 3000Vrms 1.4Ohm Prim. DCR 1.7Ohm/1.7Ohm Sec. DCR Through Hole
PDF
/
Buying Options
Total Price: USD $2.01
Unit Price: USD $2.011363
≥1 USD $2.011363
≥200 USD $0.77855
≥500 USD $0.750979
≥1000 USD $0.73785
Inventory: 1504
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 10
Weight 0.011lb 4.99g
Technical
Packaging Tray
Published 2006
Series THT
Size / Dimension 0.810Lx0.580W 20.57mmx14.73mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Invasive
Max Operating Temperature 130°C
Min Operating Temperature -40°C
Shielding Unshielded
Depth 14.73mm
Current Rating 35A
Frequency 500kHz
Termination Style PC Pin
Approval Agency UL
Physical Dimension L20.57XB14.73XH19.05 (mm)
Inductance 19mH
DC Resistance (DCR) 1.4Ohm Primary 1.7mOhm Secondary
Lead/Base Style PC Pin
Frequency Range 50kHz~500kHz
Isolation Voltage 3kV
Turns Ratio - Primary:Secondary 100:1
Dimensions
Height 19.05mm
Height Seated (Max) 0.750 19.05mm
Length 20.57mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
