FIS101NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
CURR SENSE XFMR 1:50 15A T/H
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.684
≥1 USD $2.684
≥10 USD $2.17184
≥100 USD $1.756128
≥500 USD $1.645283
≥1000 USD $1.571363
≥3000 USD $1.525181
Inventory: 94
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Technical
Packaging Tube
Published 2015
Series FIS
Size / Dimension 0.677Lx0.375W 17.20mmx9.53mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Non-Invasive (Solid Core)
HTS Code 8504.50.80.00
Current Rating (Amps) 15A
Termination Style PC Pin
Inductance 5mH
DC Resistance (DCR) 650mOhm Secondary Max
Frequency Range 200kHz Max
Turns Ratio - Primary:Secondary 1:50
ET (Volt-Time) 175VμS
Dimensions
Height Seated (Max) 0.803 20.40mm
Compliance
RoHS Status RoHS Compliant
