H1300FNLT image
Favorite
H1300FNLT image
Favorite
RoHS
/
Package /
Category Transformers / Current Sense Transformers
Description Telecom Transformer 1.414CT:1CT/1.414CT:1CT 1500Vrms -1.2dB Surface Mount
PDF
/
Inventory: 2322
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.236 5.99mm

Technical

Turns Ratio - Primary:Secondary 1.414:1
DC Resistance (DCR) 65mOhm Secondary Max
Inductance 350μH
Termination Style Gull Wing
Type Invasive
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.500Lx0.358W 12.70mmx9.09mm
Published 2013
Packaging Tape & Reel (TR)

Physical

Number of Pins 16
Mounting Type Surface Mount
Mount Surface Mount
