H1300FNL
RoHS
/
Package /
Category Transformers / Current Sense Transformers
Description
10/100 TRANSFORMER 1.41:1. / 1.4
PDF
/
Inventory: 2816
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.236 5.99mm
Technical
Turns Ratio - Primary:Secondary 1.414:1
DC Resistance (DCR) 65mOhm Secondary Max
Inductance 350μH
Termination Style Gull Wing
Type Invasive
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.500Lx0.358W 12.70mmx9.09mm
Published 2013
Packaging Bulk
Physical
Number of Pins 16
Mounting Type Surface Mount
Mount Surface Mount
