B82801C0145A050
RoHS
/
Package /
Category Transformers / Current Sense Transformers
Description
10 WOUND PRIMARY Surface Mount TAPE & REEL Current Sense Transformer 0.4Ohm 40A 1.4mH 50kHz
PDF
/
Buying Options
Total Price: USD $3.26
Unit Price: USD $3.256
≥1 USD $3.256
≥10 USD $2.63824
≥100 USD $2.133472
≥500 USD $1.998656
≥1000 USD $1.908808
Inventory: 412
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Mount Surface Mount
Number of Pins 10
Weight 4.8g
Technical
Pbfree Code yes
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 130°C
Min Operating Temperature -40°C
Packing Method TAPE & REEL
Depth 19.91mm
Current Rating 40A
Inductance 1.4 mH
Frequency (Max) 500kHz
Lead/Base Style Gull Wing
DC Resistance (DCR) - Parallel 400mOhm
Operating Frequency-Min 50kHz
Transformer Type CURRENT SENSE TRANSFORMER
Turns Ratio - Primary:Secondary 1:50
Current - Input 40A
Load Resistance 0.4Ohm
Primary Type WOUND PRIMARY
Dimensions
Height 10mm
Length 14.22mm
Width 13.46mm
Compliance
RoHS Status RoHS Compliant
