B82801B0504A050
RoHS
/
Package SMD/SMT
Category Transformers / Current Sense Transformers
Description
6 BAR PRIMARY Surface Mount LENGTH AND HEIGHT DIMENSION INCLUDES TERMINAL ALSO Current Sense Transformer 500muH 1Hz 8.38mm 130C
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.8128
≥1 USD $1.8128
≥10 USD $1.45288
≥100 USD $1.180256
≥500 USD $1.15016
≥1000 USD $1.1198
≥3000 USD $1.089546
Inventory: 7388
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7.11mm
Length 7.11mm
Technical
Primary Type BAR PRIMARY
Current - Input 20A
Turns Ratio - Primary:Secondary 1:50
Transformer Type CURRENT SENSE TRANSFORMER
DC Resistance (DCR) - Parallel 1.5Ohm
Lead/Base Style Gull Wing
Frequency (Max) 1MHz
Inductance 500 μH
Physical Dimension L8.38XB7.11XH5.08 (mm)
Frequency 1Hz
Depth 8.38mm
Packing Method TAPE & REEL
Additional Feature LENGTH AND HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Min Operating Temperature -40°C
Max Operating Temperature 130°C
ECCN Code EAR99
Pbfree Code yes
Physical
Weight 400mg
Number of Pins 6
Package / Case SMD/SMT
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
