AS-100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
TRANSFORMER CURRENT 15A 1:50 VRT
PDF
/
Buying Options
Total Price: USD $3.69
Unit Price: USD $3.6872
≥1 USD $3.6872
≥10 USD $2.98672
≥100 USD $2.41472
≥500 USD $2.26226
≥1000 USD $2.16062
≥3000 USD $2.097119
Inventory: 784
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9.53mm
Length 17.2mm
Height Seated (Max) 0.803 20.40mm
Technical
ET (Volt-Time) 175VμS
Turns Ratio - Primary:Secondary 1:50
Frequency Range 20kHz~200kHz
DC Resistance (DCR) 600mOhm Max
Inductance 6mH
Termination Style PC Pin
Frequency 200kHz
Current Rating 15A
Type Non-Invasive (Solid Core)
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.677Lx0.375W 17.20mmx9.53mm
Series AS
Published 2007
Packaging Tray
Physical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
