AX16000004
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Crystals, Oscillators, Resonators / Crystals
Description
CRYSTAL 16MHZ 22PF SMD
PDF
/
Inventory: 5206
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, No Lead
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2011
Series AX
Size / Dimension 0.315Lx0.177W 8.00mmx4.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type MHz Crystal
Frequency 16MHz
Frequency Stability ±100ppm
ESR (Equivalent Series Resistance) 80Ohm
Load Capacitance 22pF
Operating Mode Fundamental
Frequency Tolerance ±30ppm
Dimensions
Height 1.4986mm
Height Seated (Max) 0.059 1.50mm
Compliance
RoHS Status RoHS Compliant
Ratings AEC-Q200
