ECS-150-18-7SX-TR
RoHS
RoHS compliant
RoHS compliantPackage 4-SOJ, 9.40mm pitch
Category Crystals, Oscillators, Resonators / Crystals
Description
Fundamental Active ROHS3Compliant 2007 Crystal 18pF 4.5974mm -10C~70C 50Ohms
PDF
/
Buying Options
Total Price: USD $7.15
Unit Price: USD $7.147428
≥1 USD $7.147428
≥200 USD $2.851619
≥500 USD $2.75709
≥1000 USD $2.709826
Inventory: 4778
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SOJ, 9.40mm pitch
Technical
Operating Temperature -10°C~70°C
Packaging Tape & Reel (TR)
Published 2007
Series ECX-3SX
Size / Dimension 0.492Lx0.181W 12.50mmx4.60mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type MHz Crystal
Max Operating Temperature 70°C
Min Operating Temperature -10°C
Frequency 15MHz
Frequency Stability ±50ppm
ESR (Equivalent Series Resistance) 50Ohms
Load Capacitance 18pF
Operating Mode Fundamental
Frequency Tolerance ±30ppm
Dimensions
Height 3.7084mm
Height Seated (Max) 0.146 3.70mm
Length 12.4968mm
Width 4.5974mm
Compliance
RoHS Status ROHS3 Compliant
