RoHS
/
Package /
Category Tools / Crimpers, Applicators, Presses - Accessories
Description
SURFACE MOUNT BLACK ROHS AND ELV COMPLIANT NYLON (Accessory Type) Tool 0.364inch 1500VAC V 105C 5A
PDF
/
Inventory: 5426
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mounting Type BOARD
Insulation Material NYLON
Shell Material POLYAMIDE
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Mounting Option 2 LATCHING
Technical
Pbfree Code yes
Connector Type COMBINATION LINE CONNECTOR
Number of Rows 2
Additional Feature ROHS AND ELV COMPLIANT
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 8
Terminal Pitch 2.9972mm
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.63 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Mating Information 794617-8
Body Breadth 0.27 inch
Contact Gender MALE
Operating Temperature (Min) -40°C
UL Flammability Code 94V-0
Empty Shell NO
Body Depth 0.364 inch
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
Insulation Resistance 100000000Ohm
Mating Contact Pitch 0.118 inch
Body/Shell Style RECEPTACLE
Termination Type SURFACE MOUNT
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1500VAC V
PCB Contact Row Spacing 9.398 mm
Durability 75 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 6.672 N
Withdrawl Force-Min .6672 N
Insulator Color BLACK
Dimensions
Plating Thickness 15μin
Compliance
RoHS Status Non-RoHS Compliant
