314013-1
RoHS
/
Package /
Category Tools / Crimpers, Applicators, Presses - Accessories
Description
PRESS FIT GLASS FILLED POLYESTER RECEPTACLE STRAIGHT (Accessory Type) Tool 0.525inch 1000VAC V 120C
PDF
/
Inventory: 5606
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type BOARD
Insulation Material GLASS FILLED POLYESTER
Mounting Style STRAIGHT
Technical
Connector Type BOARD CONNECTOR
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating AU ON NI
Mixed Contacts YES
Total Number of Contacts 280
Reach Compliance Code unknown
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 8.92 inch
Operating Temperature (Max) 120°C
Body Breadth 0.586 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
Body Depth 0.525 inch
Contact Style HYBRID
Insulation Resistance 100000000000Ohm
Body/Shell Style RECEPTACLE
Termination Type PRESS FIT
Dielectric Withstanding Voltage 1000VAC V
Contact Finish Termination GOLD
Contact Arrangement S248P32
Dimensions
Plating Thickness 30μin
Length - Termination 0.188 inch
Compliance
RoHS Status Non-RoHS Compliant
