300115
RoHS
/
Package /
Category Tools / Crimpers, Applicators, Presses - Accessories
Description
POLYPHENYLENE SULPHIDE 2 PLUG POLARIZATION POST (Accessory Type) Tool 0.4inch 500VAC V 120C 2A
PDF
/
Buying Options
Total Price: USD $24.84
Unit Price: USD $24.836534
≥1 USD $24.836534
≥10 USD $23.430701
≥100 USD $22.104423
≥500 USD $20.853233
≥1000 USD $19.672864
Inventory: 1197
Minimum: 1
-
+
Technical Details
Physical
Contact Material COPPER ALLOY
Insulation Material POLYPHENYLENE SULPHIDE
Mounting Style STRAIGHT
Board Mounting Option POLARIZATION POST
Technical
Connector Type BOARD CONNECTOR
Number of Rows 4
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating AU ON NI
Total Number of Contacts 60
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 4.38 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 120°C
Body Breadth 0.486 inch
Contact Gender FEMALE
Operating Temperature (Min) -55°C
Body Depth 0.4 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.1 inch
Body/Shell Style PLUG
Polarization Key POLAR PIN POSITION
Dielectric Withstanding Voltage 500VAC V
Contact Finish Termination GOLD
Contact Pattern RECTANGULAR
Insertion Force-Max 2.224 N
Withdrawl Force-Min .278 N
Mating Contact Row Spacing 0.1 inch
Dimensions
Plating Thickness 30μin
Compliance
RoHS Status Non-RoHS Compliant
