E5GN-R2TD AC/DC24
RoHS
/
Package /
Category Industrial Automation and Controls / Controllers - Process, Temperature
Description
CONTROL TEMP RELAY OUT 24V
PDF
/
Inventory: 3336
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Panel Mount
Weight 0.198lb 89.81g
Technical
Operating Temperature -10°C~55°C
Published 2008
Series E5GN
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Temperature Controller (RTD, Type B, E, J, K, L, N, PLII, R, S, T, U, W)
Voltage - Supply 24VAC/DC
Ingress Protection IP66 - Dust Tight, Water Resistant
Termination Style Screw Terminal
Output Type Relay (3)
Panel Cutout Dimensions Rectangular - 45.00mm x 22.20mm
Display Type LCD - Dual Color Characters, Backlight
Input Range -200°C ~ 2300°C, 0 ~ 50mV
Number of Characters Per Row 4, 4
Control Method On/Off, Proportional (PID)
Dimensions
Display Characters - Height 0.295 7.50mm 0.142 3.60mm
