E5GC-RX0DCM-000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Industrial Automation and Controls / Controllers - Process, Temperature
Description
CONTROL TEMP/PROC RELAY OUT 24V
PDF
/
Buying Options
Total Price: USD $359.9
Unit Price: USD $359.902651
≥1 USD $359.902651
≥200 USD $139.277684
≥500 USD $134.383192
≥1000 USD $131.964831
Inventory: 1512
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Panel
Mounting Type Panel Mount
Weight 0.176lb 79.83g
Technical
Operating Temperature -10°C~55°C
Published 2014
Series E5GC
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
Type Process, Temperature Controller (Type B, E, J, K, L, N, PLII, R, S, T, U, W)
Max Operating Temperature 55°C
Min Operating Temperature -10°C
Voltage - Supply 24VAC/DC
Ingress Protection IP66 - Dust Tight, Water Resistant
Termination Style Spring Terminal
Output Type Relay
Panel Cutout Dimensions Rectangular - 45.00mm x 22.20mm
Display Type LCD - Dual Color Characters, Backlight
Input Range -200°C ~ 2300°C, 0 ~ 20mA, 0 ~ 10VDC
Number of Characters Per Row 4, 4
Control Method On/Off, Proportional (PID)
Dimensions
Display Characters - Height 0.413 10.50mm 0.197 5.00mm
Compliance
RoHS Status RoHS Compliant
Ratings IP66
