E5CC-RX3A5M-001
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Industrial Automation and Controls / Controllers - Process, Temperature
Description
Controller,Temperature,1/16 DIN,Relay Output,HB
PDF
/
Buying Options
Total Price: USD $291.21
Unit Price: USD $291.2096
≥1 USD $291.2096
≥10 USD $281.50232
Inventory: 110
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP66
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Display Characters - Height 0.600 15.20mm 0.280 7.10mm
Width 48mm
Height 48mm
Technical
Min Supply Voltage (AC) 100V
Control Method On/Off, Proportional (PID)
Number of Characters Per Row 4, 4
Input Range -200°C ~ 2300°C, 0 ~ 20mA, 0 ~ 10VDC
Max Supply Voltage (AC) 240V
Display Type LCD - Dual Color Characters, Backlight
Number of Inputs 1
Panel Cutout Dimensions Square - 45.00mm x 45.00mm
Operating Supply Voltage 240V
Output Type Relay (4)
Output Voltage 250V
Number of Outputs 3
Termination Style Screw Terminal
Ingress Protection IP66 - Dust Tight, Water Resistant
Voltage - Supply 100V~240VAC
Min Operating Temperature -10°C
Max Operating Temperature 55°C
Type Process, Temperature Controller (RTD, Type B, E, J, K, L, N, PLII, R, S, T, U, W)
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Event Input, Heater Fault Detection
Series E5CC
Published 2011
Operating Temperature -10°C~55°C
Physical
Weight 0.265lb 120.2g
Package / Case 100
Mounting Type Panel Mount
Mount Brackets, Panel
Supply Chain
Factory Lead Time 2 Weeks
