E5CC-QQ3D5M-003
RoHS
RoHS compliant
RoHS compliantPackage /
Category Industrial Automation and Controls / Controllers - Process, Temperature
Description
Controller,Temperature,1/16 DIN,2 Voltage Outputs,HB,4 Events
PDF
/
Buying Options
Total Price: USD $439.08
Unit Price: USD $439.0848
≥1 USD $439.0848
≥10 USD $424.44864
Inventory: 47
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP66
RoHS Status RoHS Compliant
Dimensions
Display Characters - Height 0.600 15.20mm 0.280 7.10mm
Technical
Communications RS-485 (CompoWay/F, Modbus)
Control Method On/Off, Proportional (PID)
Number of Characters Per Row 4, 4
Input Range -200°C ~ 2300°C, 0 ~ 20mA, 0 ~ 10VDC
Display Type LCD - Dual Color Characters, Backlight
Number of Inputs 1
Panel Cutout Dimensions Square - 45.00mm x 45.00mm
Operating Supply Voltage 24V
Output Type Relay (3), Voltage (External SSR) (2)
Number of Outputs 3
Termination Style Screw Terminal
Ingress Protection IP66 - Dust Tight, Water Resistant
Voltage - Supply 24VAC/DC
Min Operating Temperature -10°C
Max Operating Temperature 55°C
Type Process, Temperature Controller (RTD, Type B, E, J, K, L, N, PLII, R, S, T, U, W)
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Heater Fault Detection
Series E5CC
Published 2011
Operating Temperature -10°C~55°C
Physical
Weight 0.265lb 120.2g
Mounting Type Panel Mount
Mount Brackets, Panel
