E5AC-CC4A5M-000
RoHS
/
Package 100
Category Industrial Automation and Controls / Controllers - Process, Temperature
Description
4 Screw Terminal Process Temperature Controller (RTD Type B E J K L N PLII R S T U W) 100 Temperature Controller 100V~240VAC -200C-2300C 0-20mA 0-10VDC -10C~55C
PDF
/
Buying Options
Total Price: USD $526.9
Unit Price: USD $526.9
≥1 USD $526.9
≥10 USD $509.33872
Inventory: 67
Minimum: 1
-
+
Technical Details
Physical
Mount Brackets, Panel
Mounting Type Panel Mount
Package / Case 100
Weight 0.551lb 249.93g
Technical
Operating Temperature -10°C~55°C
Published 2012
Series E5AC
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Process, Temperature Controller (RTD, Type B, E, J, K, L, N, PLII, R, S, T, U, W)
Max Operating Temperature 55°C
Min Operating Temperature -10°C
Voltage - Supply 100V~240VAC
Ingress Protection IP66 - Dust Tight, Water Resistant
Termination Style Screw Terminal
Number of Outputs 4
Output Type Analog (2), Relay (4)
Panel Cutout Dimensions Square - 92.00mm x 92.00mm
Number of Inputs 1
Display Type LCD - Tri Color Characters, Backlight
Input Range -200°C ~ 2300°C, 0 ~ 20mA, 0 ~ 10VDC
Number of Characters Per Row 4, 4, 4
Control Method On/Off, Proportional (PID)
Dimensions
Display Characters - Height 0.984 25.00mm 0.590 15.00mm 0.374 9.50mm
Compliance
RoHS Status Non-RoHS Compliant
Ratings IP66
