2867144
RoHS
/
Package Module
Category Industrial Automation and Controls / Controllers - PLC Modules
Description
Terminal Block Interface Modules I/O MOD. 8CH DIGITAL
PDF
/
Inventory: 1148
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Package / Case Module
Housing Material Polyamide
Weight 0.388lb 175.99g
Technical
Operating Temperature -20°C~65°C
Published 2010
Series RAD
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Input Module
Number of Positions 8
Max Operating Temperature 65°C
Min Operating Temperature -20°C
Color Green
Voltage - Rated DC 9V
Voltage - Supply 9V~30VDC
Ingress Protection IP20
Depth 114.5mm
Current Rating 25mA
Termination Style Screw Terminal
Approval Agency ATEX, CE, cUL, cULus, UL
Output Type Digital
Number of Channels 8
Number of Inputs 8
Max Input Current 30mA
Max Input Voltage (DC) 5V
Min Input Voltage (DC) 1.5V
Number of Inputs and Type 8 - Digital
Dimensions
Height 99mm
Length 114.5mm
Width 22.5mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Ratings IP20
