CJ1W-PA202
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Industrial Automation and Controls / Controllers - PLC Modules
Description
POWER SUPPLY MODULE 100-240V
PDF
/
Buying Options
Total Price: USD $238.81
Unit Price: USD $238.8056
≥1 USD $238.8056
≥10 USD $230.84864
≥100 USD $214.928032
Inventory: 300
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Package / Case Module
Weight 11lbs 5kg
Technical
Operating Temperature 0°C~55°C
Published 2004
Series CJ1W
Feature Output Capacity (5VDC, 2.8A, 14W)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Power Supply Module
Max Operating Temperature 55°C
Min Operating Temperature 0°C
Voltage - Supply 100V~240VAC
Depth 45mm
Termination Style Screw Terminal
Number of Outputs 1
Approval Agency CE, cULus, Lloyd, NK
Voltage - Output 1 5V
Output Current 400mA
Output Power 14W
Current - Output 1 2.8A
Dimensions
Height 90mm
Length 81.6mm
Width 45mm
Compliance
RoHS Status RoHS Compliant
