7789043030
RoHS
/
Package DIP
Category Industrial Automation and Controls / Controllers - Cable Assemblies
Description
CABLE ASSEMBLY INTERFACE 9.84'
PDF
/
Inventory: 5960
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 9.84' 3.00m
Technical
Control Side Connection Controller Specific Connector
Process Side Connection D-Sub Connector
Input Bias Current 5μA
-3db Bandwidth 180MHz
Specifications Interface
Input Offset Voltage (Vos) 30mV
Output Current per Channel 250mA
Slew Rate 2000 V/μs
Cable Length 3m
Operating Supply Current 15mA
Connector Support Type CABLE ASSEMBLY
Number of Circuits 1
Approval Agency cULus, UL
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 15
Resistance 80MOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Published 2013
Physical
Material PVC
Package / Case DIP
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
