770986-3
RoHS
/
Package 600
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
Standard Circular Contacts SOCKET 26-22 BULK MINI UMNL
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.66
≥1 USD $0.66
≥10 USD $0.63448
≥100 USD $0.511896
≥500 USD $0.397223
≥1000 USD $0.34657
≥3000 USD $0.329947
Inventory: 1127
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 1.27μm
Contact Finish Thickness 30.0μin 0.76μm
Length 17.11mm
Height 2.92mm
Technical
Cable Entry-Min 0.047 inch
Cable Entry-Max 0.069 inch
VDE Tested Yes
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 1.75 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 9.5A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
Wire/Cable Type Discrete
Max Current Rating 9.5A
ELV Non-Compliant
Wire Gauge 22-26 AWG
Operating Supply Voltage 600V
Contact Gender Female
Approval Agency UL
Voltage - Rated AC 600V
Contact Finish Gold
Current Rating 9.5A
Depth 2.95mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 600V
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Series Mini-Universal MATE-N-LOK
Published 2005
Packaging Bulk
Physical
Underplate Material Nickel
Package / Case 600
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 14 Weeks
