745229-4 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description CONN PIN 18-22AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.31944
≥100 USD $0.265936
≥500 USD $0.198114
≥1000 USD $0.176845
≥3000 USD $0.16456
Inventory: 1192
Minimum: 1
-
+

Technical Details

Technical

Pin or Socket Pin
Assembly Item Name CONTACT
Insulation Diameter 1.7272 mm
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 18 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 18 AWG
Max Current Rating 3.1A
ELV Compliant
Wire Gauge 18-22 AWG
Lead Length 9.9314mm
Operating Temperature (Min) -55°C
Contact Gender Male
Contact Finish Gold
Depth 2.29mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Type Stamped
ECCN Code EAR99
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPLIMITE HDP-20
Published 2004
Packaging Bulk

Dimensions

Length 14.22mm
Contact Finish Thickness 30.0μin 0.76μm

Compliance

Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free

Physical

Mount Cable
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 12 Weeks
