66682-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
TE CONNECTIVITY / AMP 66682-4D SUB CONTACT, PIN, 28-24AWG, CRIMP
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.16896
≥100 USD $0.140536
≥500 USD $0.116838
≥1000 USD $0.097997
≥3000 USD $0.086152
Inventory: 1170
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 14.86mm
Technical
Cable Entry-Min 0.05 inch
Cable Entry-Max 0.06 inch
Max Supply Voltage (AC) 250V
Assembly Item Name CONTACT
Pin or Socket Pin
Wire/Cable Diameter 1.524 mm
Insulation Diameter 1.524 mm
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 24 AWG
Max Current Rating 1.2A
ELV Compliant
Wire Gauge 24-28 AWG
Lead Length 9.906mm
Contact Gender Male
Contact Finish Gold
Current Rating 3.7A
Depth 2.41mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Gender Female
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Type Stamped
ECCN Code EAR99
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPLIMITE HDP-20
Published 2004
Packaging Bulk
Physical
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 13 Weeks
