66601-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN SOCKET 14-18AWG TIN CRIMP
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
≥10 USD $0.7524
≥100 USD $0.719136
≥500 USD $0.709104
≥1000 USD $0.619608
≥3000 USD $0.596429
Inventory: 24368
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Brass
Mount Cable
Underplate Material Nickel
Technical
Packaging Bulk
Published 2004
Series Multimate III+
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Stamped
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Orientation Straight
Shielding Shielded
Depth 4.32mm
Current Rating 13A
Contact Finish Tin
Contact Gender Female
Wire Gauge 14-18 AWG
Max Current Rating 13A
Wire/Cable Type Discrete
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge 14 AWG
Circuit Application Signal
Contact Termination Crimp
Insulation Diameter 3.81 mm
Pin or Socket Socket
Dimensions
Length 20.96mm
Contact Finish Thickness 50.0μin 1.27μm
Plating Thickness 2.54μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
