66570-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN PIN 18AWG SLD CUP GOLD
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.36608
≥100 USD $0.365024
≥500 USD $0.355696
≥1000 USD $0.305184
≥3000 USD $0.276038
Inventory: 62306
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Brass
Mount Cable
Technical
Packaging Tape & Reel (TR)
Published 2000
Series AMPLIMITE HDP-20
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
Termination Solder
ECCN Code EAR99
Type Stamped
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Gender Male
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 2.15mm
Contact Finish Gold
Lead Length 9.906mm
Wire Gauge 18 AWG
ELV Compliant
Max Current Rating 3.1A
Wire/Cable Gauge 18 AWG
Circuit Application Signal
Contact Termination Solder Cup
Pin or Socket Pin
Assembly Item Name CONTACT
Dimensions
Height 2.15mm
Length 14.98mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Not Applicable
