66565-3
RoHS
RoHS compliant
RoHS compliantPackage 062
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN SOCKET 20-24AWG GOLD CRIMP
PDF
/
Inventory: 2282
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 380 nm
Contact Finish Thickness 15.0μin 0.38μm
Technical
Pin or Socket Socket
Insulation Diameter 3.05 mm
Test Current 13A
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 20 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 13A
ELV Compliant
Wire Gauge 20-24 AWG
Contact Gender Female
Contact Finish Gold
Current Rating 13A
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Connector, Power, Signal, Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multimate III+
Published 2004
Packaging Bulk
Physical
Underplate Material Nickel
Package / Case 062
Contact Plating Gold, Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Factory Lead Time 9 Weeks
