66505-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN SOCKET 24-28AWG GOLD CRIMP
PDF
/
Inventory: 7574
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Contact Termination Crimp
Contact Design LOOSE
Pin or Socket Socket
Assembly Item Name CONTACT
Cable Entry-Max 0.04 inch
Cable Entry-Min 0.03 inch
Packaging Tape & Reel (TR)
Published 2005
Series AMPLIMITE HDP-20
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Connector, Power
Type Stamped
Max Operating Temperature 105°C
Min Operating Temperature -55°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 1.52mm
Reach Compliance Code unknown
Contact Finish Gold
Contact Gender FEMALE
Wire Gauge 24-28 AWG
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 24 AWG
Dimensions
Height 1.52mm
Length 14.09mm
Contact Finish Thickness 50.0μin 1.27μm
Compliance
RoHS Status RoHS Compliant
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Phosphor Bronze
Mount Cable
Material Bronze
