66406-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN PIN 26-30AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $1.08
Unit Price: USD $1.0824
≥1 USD $1.0824
≥10 USD $0.98824
≥100 USD $0.958848
≥500 USD $0.948992
≥1000 USD $0.880968
≥3000 USD $0.866342
Inventory: 13471
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Physical
Contact Material Brass
Contact Plating Tin
Mount Cable
Contact Shape Round
Underplate Material Nickel
Technical
Packaging Bulk
Published 2004
Series Multimate III+
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
ECCN Code EAR99
Type Stamped
Number of Positions 24
Max Operating Temperature 221°C
Min Operating Temperature -67°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Pitch 2.54mm
Orientation Straight
Depth 1.68mm
Current Rating 13A
Contact Finish Gold
Approval Agency UL
Contact Gender Male
Wire Gauge 26-30 AWG
ELV Compliant
Max Current Rating 13A
Wire/Cable Type Discrete
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 26 AWG
Wire/Cable Gauge 26 AWG
Circuit Application Signal
Contact Termination Crimp
Test Current 13A
Insulation Diameter 762 μm
Pin or Socket Pin
Assembly Item Name CONTACT
Cable Entry-Max 0.03 inch
Used With CPC, G SERIES AND M SERIES CONNECTOR
Dimensions
Height 1.68mm
Length 27.56mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 760 nm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
