66109-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN SOCKET 24-26AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2144
≥1 USD $1.2144
≥10 USD $1.13344
≥100 USD $1.090848
≥500 USD $1.080464
≥1000 USD $0.97504
≥3000 USD $0.943395
Inventory: 6317
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Brass
Contact Plating Gold, Tin
Mount Cable
Underplate Material Nickel
Technical
Packaging Bulk
Published 2004
Series Multimate III+
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
ECCN Code EAR99
Type Stamped
Max Operating Temperature 125°C
Min Operating Temperature -55°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 2.41mm
Current Rating 13A
Contact Finish Gold
Approval Agency UL
Contact Gender Female
Operating Supply Voltage 600V
Wire Gauge 24-26 AWG
ELV Compliant
Max Current Rating 13A
Wire/Cable Type Discrete
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 24 AWG
Wire/Cable Gauge 24 AWG
Circuit Application Signal
Contact Termination Crimp
Test Current 13A
Insulation Diameter 1.397 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Cable Entry-Max 0.055 inch
Cable Entry-Min 0.035 inch
Used With CPC, G SERIES AND M SERIES CONNECTOR
Dimensions
Height 1.7mm
Length 13.46mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 760 nm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
