66106-7
RoHS
RoHS compliant
RoHS compliantPackage 062
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN PIN .062 24-26AWG AU CRIMP
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.0736
≥1 USD $1.0736
≥10 USD $1.00584
≥100 USD $0.968704
≥500 USD $0.959376
≥1000 USD $0.865832
≥3000 USD $0.83776
Inventory: 69919
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Brass
Contact Plating Gold, Tin
Mount Cable
Package / Case 062
Underplate Material Nickel
Technical
Packaging Cut Tape (CT)
Published 1998
Series Multimate III+
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Stamped
Max Operating Temperature 200°C
Min Operating Temperature -196°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 2.87mm
Contact Finish Gold
Approval Agency UL
Contact Gender Male
Wire Gauge 24-26 AWG
ELV Compliant
Max Current Rating 13A
Wire/Cable Type Discrete
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 24 AWG
Wire/Cable Gauge 26 AWG
Circuit Application Signal
Contact Termination Crimp
Test Current 13A
Insulation Diameter 1.397 mm
Pin or Socket Pin
Assembly Item Name CONTACT
VDE Tested Yes
Cable Entry-Max 0.055 inch
Cable Entry-Min 0.035 inch
Used With CPC, G SERIES AND M SERIES CONNECTOR
Dimensions
Length 27.1mm
Contact Finish Thickness 15.0μin 0.38μm
Plating Thickness 380 nm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
