66105-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN SOCKET 20-24AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $1.33
Unit Price: USD $1.3288
≥1 USD $1.3288
≥10 USD $1.21792
≥100 USD $1.182016
≥500 USD $1.170048
≥1000 USD $1.086008
≥3000 USD $1.068003
Inventory: 6188
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Brass
Contact Plating Gold, Tin
Mount Cable
Underplate Material Nickel
Technical
Packaging Bulk
Published 1999
Series Multimate III+
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Stamped
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Depth 2.92mm
Current Rating 13A
Contact Finish Gold
Operating Temperature (Max) 90°C
Contact Gender Female
Operating Temperature (Min) -55°C
Wire Gauge 20-24 AWG
ELV Compliant
Max Current Rating 13A
Wire/Cable Type Discrete
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 20 AWG
Wire/Cable Gauge 20 AWG
Circuit Application Signal
Contact Termination Crimp
Test Current 13A
Insulation Diameter 2.03 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Cable Entry-Max 0.08 inch
Cable Entry-Min 0.04 inch
Used With CPC, G SERIES AND M SERIES CONNECTOR
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 760 nm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
