66103-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN PIN 20-24AWG 30 GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.1528
≥1 USD $1.1528
≥10 USD $1.078
≥100 USD $1.037344
≥500 USD $1.027488
≥1000 USD $0.927256
≥3000 USD $0.897142
Inventory: 1147
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Length 27.48mm
Diameter 1.57 mm
Technical
Used With CPC, G SERIES AND M SERIES CONNECTOR
Cable Entry-Min 0.04 inch
Cable Entry-Max 0.08 inch
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 2.03 mm
Test Current 13A
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 20 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 24 AWG
Wire/Cable Type Discrete
Max Current Rating 13A
ELV Compliant
Wire Gauge 20-24 AWG
Contact Gender Male
Contact Finish Gold
Current Rating 13A
Depth 2.92mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 250V
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Type Stamped
ECCN Code EAR99
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Multimate III+
Published 1999
Packaging Bulk
Physical
Underplate Material Nickel
Mount Cable, Panel
Contact Plating Gold, Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 4 Weeks
