66103-2
RoHS
/
Package /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN PIN 20-24AWG TIN-LEAD CRIMP
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.5632
≥1 USD $0.5632
≥10 USD $0.53592
≥100 USD $0.512512
≥500 USD $0.505472
≥1000 USD $0.441672
≥3000 USD $0.425146
Inventory: 13966
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Brass
Contact Plating Lead, Tin
Mount Cable
Weight 10.341906g
Underplate Material Nickel
Technical
Packaging Bulk
Published 1998
Series Multimate III+
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
ECCN Code EAR99
Type Stamped
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 2.92mm
Reach Compliance Code not_compliant
Contact Finish Tin-Lead
Operating Temperature (Max) 90°C
Contact Gender Male
Operating Temperature (Min) -55°C
Wire Gauge 20-24 AWG
ELV Non-Compliant
Max Current Rating 13A
Plating Lead, Tin
Wire/Cable Type Discrete
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 20 AWG
Wire/Cable Gauge 20 AWG
Circuit Application Signal
Contact Termination Crimp
Test Current 13A
Insulation Diameter 2.03 mm
Pin or Socket Pin
Assembly Item Name CONTACT
Cable Entry-Max 0.08 inch
Cable Entry-Min 0.04 inch
Used With CPC, G SERIES AND M SERIES CONNECTOR
Dimensions
Height 6.35mm
Length 27.48mm
Width 76.2mm
Contact Finish Thickness 50.0μin 1.27μm
Plating Thickness 2.54μm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
