66102-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONTACT PIN 20-24AWG STRIP GOLD
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.748
≥1 USD $0.748
≥10 USD $0.71456
≥100 USD $0.683232
≥500 USD $0.673728
≥1000 USD $0.588808
≥3000 USD $0.566755
Inventory: 10953
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Brass
Contact Plating Gold, Tin
Mount Cable
Underplate Material Nickel
Technical
Packaging Tape & Reel (TR)
Published 2011
Series Multimate III+
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
ECCN Code EAR99
Type Stamped
Max Operating Temperature 105°C
Min Operating Temperature -55°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 2.92mm
Current Rating 13A
Contact Finish Gold
Contact Gender Male
Wire Gauge 20-24 AWG
ELV Compliant
Max Current Rating 13A
Wire/Cable Type Discrete
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 20 AWG
Wire/Cable Gauge 20 AWG
Circuit Application Signal
Contact Termination Crimp
Test Current 13A
Insulation Diameter 2.03 mm
Pin or Socket Pin
Assembly Item Name CONTACT
Cable Entry-Max 0.08 inch
Cable Entry-Min 0.04 inch
Used With CPC CONNECTOR
Dimensions
Length 27.48mm
Contact Finish Thickness 15.0μin 0.38μm
Plating Thickness 380 nm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
