66100-7 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description CONN SOCKET 16-18AWG TIN CRIMP
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.6688
≥1 USD $0.6688
≥10 USD $0.64768
≥100 USD $0.645216
≥500 USD $0.623392
≥1000 USD $0.52272
≥3000 USD $0.490054
Inventory: 3636
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Plating Thickness 2.54μm
Contact Finish Thickness 50.0μin 1.27μm
Height 3.05mm

Technical

Used With CPC, G SERIES AND M SERIES CONNECTOR
Cable Entry-Min 0.08 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.54 mm
Test Current 13A
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 16 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 18 AWG
Number of Ports 1
Wire/Cable Type Discrete
Plating Lead, Tin
Max Current Rating 13A
ELV Non-Compliant
Wire Gauge 16-18 AWG
Operating Temperature (Min) -55°C
Contact Gender Female
Operating Temperature (Max) 90°C
Contact Finish Tin-Lead
Depth 3.68mm
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Number of Positions 16
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Series Multimate III+
Published 1998
Packaging Cut Tape (CT)

Physical

Underplate Material Nickel
Mount Cable
Contact Plating Lead, Tin
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 4 Weeks
