66098-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONTACT PIN 16-18AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.9856
≥1 USD $0.9856
≥10 USD $0.92136
≥100 USD $0.887392
≥500 USD $0.878944
≥1000 USD $0.793144
≥3000 USD $0.76743
Inventory: 11984
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 380 nm
Contact Finish Thickness 15.0μin 0.38μm
Length 27.1mm
Technical
Used With CPC CONNECTOR
Cable Entry-Min 0.08 inch
Cable Entry-Max 0.1 inch
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 2.54 mm
Test Current 13A
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 16 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 18 AWG
Wire/Cable Type Discrete
Max Current Rating 13A
ELV Compliant
Wire Gauge 16-18 AWG
Operating Temperature (Min) -55°C
Contact Gender MALE
Operating Temperature (Max) 90°C
Contact Finish Gold
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multimate III+
Published 2008
Packaging Tape & Reel (TR)
Physical
Underplate Material Nickel
Contact Shape Round
Mount Cable
Contact Plating Gold, Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 5 Weeks
