66098-2 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description CONTACT PIN 16-18AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.59752
≥100 USD $0.595232
≥500 USD $0.575168
≥1000 USD $0.48224
≥3000 USD $0.452074
Inventory: 1386
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Plating Thickness 2.54μm
Contact Finish Thickness 50.0μin 1.27μm
Length 27.1mm

Technical

Used With M SERIES CONNECTOR
Cable Entry-Min 0.08 inch
Cable Entry-Max 0.1 inch
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 2.54 mm
Test Current 13A
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 16 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 18 AWG
Wire/Cable Type Discrete
Plating Lead, Tin
Max Current Rating 13A
ELV Non-Compliant
Wire Gauge 16-18 AWG
Operating Temperature (Min) -55°C
Contact Gender MALE
Operating Temperature (Max) 90°C
Contact Finish Tin-Lead
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multimate III+
Published 1998
Packaging Tape & Reel (TR)

Physical

Underplate Material Nickel
Contact Shape Round
Mount Cable
Contact Plating Lead, Tin
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 5 Weeks
