5-66505-9
RoHS
/
Package /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN SOCKET 24-28AWG GOLD CRIMP
PDF
/
Inventory: 1169
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness Flash
Length 14.35mm
Technical
Cable Entry-Min 0.03 inch
Cable Entry-Max 0.04 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Contact Design LOOSE
Insulation Diameter 1.02 mm
Contact Termination Crimp
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
ELV Non-Compliant
Wire Gauge 24-28 AWG
Contact Finish Gold
Reach Compliance Code unknown
Depth 2.15mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Gender Female
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series AMPLIMITE HDP-20
Published 2007
Packaging Bulk
Physical
Material Bronze
Mount Cable
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
