207438-2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description Pin & Socket Connectors PIN 28-22 CRIMP TIN
PDF
/
Inventory: 2879
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Contact Current Rating 10A
Circuit Application Signal
Contact Termination Crimp
Test Current 10A
Insulation Diameter 1.37 mm
Contact Retention With
Pin or Socket Pin
Assembly Item Name CONTACT
Cable Entry-Max 0.054 inch
Cable Entry-Min 0.036 inch
Used With CPC CONNECTOR
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 28 AWG
ELV Compliant
Wire Gauge 22-28 AWG
Operating Supply Voltage 250V
Operating Temperature (Min) -55°C
Contact Gender MALE
Operating Temperature (Max) 105°C
Contact Finish Tin
Current Rating 10A
Shielding Shielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 250V
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Multimate VI
Published 1997
Packaging Tape & Reel (TR)

Dimensions

Length 20.7mm

Compliance

RoHS Status RoHS Compliant
Lead Free Not Applicable

Physical

Mount Cable
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 20 Weeks
