205310-2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description CONN PIN 24-28AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.405071
≥1 USD $0.405071
≥10 USD $0.382145
≥100 USD $0.360514
≥500 USD $0.340109
≥1000 USD $0.320845
Inventory: 1376
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 28.24mm
Height 3.18mm

Technical

Assembly Item Name CONTACT
Pin or Socket Pin
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 28 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Max Current Rating 1.2A
ELV Compliant
Wire Gauge 24-28 AWG
Operating Temperature (Min) -55°C
Contact Gender Male
Operating Temperature (Max) 105°C
Contact Finish Gold
Depth 3.18mm
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPLIMITE HDP-20
Published 2004
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 7 Weeks
