202236-1 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description CONN PIN GOLD SOLDER EYELET
PDF
/
Buying Options
Total Price: USD $3.93
Unit Price: USD $3.9336
≥1 USD $3.9336
≥10 USD $3.50504
≥100 USD $3.111856
≥500 USD $2.557438
Inventory: 2858
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Plating Thickness 250 nm
Contact Finish Thickness 30.0μin 0.76μm
Length 14.86mm
Height 2.41mm

Technical

Pin or Socket Pin
Test Current 13A
Contact Termination Solder Eyelet
Circuit Application Signal
Wire/Cable Type Discrete
Max Current Rating 3.7A
Contact Gender Male
Contact Finish Gold
Current Rating 13A
Depth 2.41mm
Orientation Straight
HTS Code 8536.90.40.00
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type Stamped
ECCN Code EAR99
Termination Solder
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multimate III+
Published 2004
Packaging Bulk

Physical

Underplate Material Nickel
Mount Cable
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 21 Weeks
