201611-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN PIN 24-28AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $4.52
Unit Price: USD $4.5232
≥1 USD $4.5232
≥10 USD $3.94328
≥100 USD $3.839264
≥500 USD $3.735424
≥1000 USD $3.653584
Inventory: 10645
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Copper Alloy
Mount Cable
Technical
Packaging Bulk
Published 1997
Series Multimate II
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Machined
Number of Positions 1
Color Blue
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Shielded
Current Rating 13A
Contact Finish Gold
Wire Gauge 24-28 AWG
ELV Compliant
Wire/Cable Type Discrete
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 24 AWG
Wire/Cable Gauge 24 AWG
Circuit Application Signal
Contact Termination Crimp
Test Current 13A
Insulation Diameter 1.397 mm
Insulation Non-Insulated
Pin or Socket Pin
Assembly Item Name CONTACT
Cable Entry-Max 0.055 inch
Cable Entry-Min 0.035 inch
Used With G Series Connectors, CPC Connectors
Dimensions
Length 27.61mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 762 nm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Not Applicable
