2-66102-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN PIN 20-24AWG TIN CRIMP
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.6424
≥1 USD $0.6424
≥10 USD $0.62304
≥100 USD $0.620928
≥500 USD $0.599808
≥1000 USD $0.50292
≥3000 USD $0.471469
Inventory: 7382
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Plating Thickness 2.54μm
Contact Finish Thickness 50.0μin 1.27μm
Length 27.48mm
Technical
Used With CPC, G SERIES AND M SERIES CONNECTOR
Cable Entry-Max 0.08 inch
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 2.03 mm
Test Current 13A
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 20 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 24 AWG
Wire/Cable Type Discrete
Max Current Rating 13A
Wire Gauge 20-24 AWG
Operating Temperature (Min) -55°C
Contact Gender Male
Operating Temperature (Max) 90°C
Contact Finish Tin
Current Rating 13A
Depth 2.92mm
Shielding Unshielded
Orientation Straight
Pitch 2.54mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Positions 4
Type Stamped
ECCN Code EAR99
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Multimate III+
Published 2004
Packaging Tape & Reel (TR)
Physical
Underplate Material Nickel
Housing Material Stainless Steel
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 5 Weeks
