2-66100-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONTACT SKT 16-18AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.476812
≥1 USD $0.476812
Inventory: 4007
Minimum: 1
-
+
Technical Details
Technical
Used With M SERIES CONNECTOR
Cable Entry-Min 0.08 inch
Cable Entry-Max 0.1 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.54 mm
Test Current 13A
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 16 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 18 AWG
Wire/Cable Type Discrete
Max Current Rating 13A
ELV Compliant
Wire Gauge 16-18 AWG
Operating Temperature (Min) -55°C
Operating Temperature (Max) 90°C
Contact Finish Tin
Depth 3.68mm
Orientation Straight
Pitch 2.54mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Number of Positions 3
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multimate III+
Published 1998
Packaging Tape & Reel (TR)
Dimensions
Height 3.05mm
Contact Finish Thickness 50.0μin 1.27μm
Plating Thickness 2.54μm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
Physical
Underplate Material Nickel
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 5 Weeks
